Image Sensor|1/2.8" Progressive Scan CMOSSignal System|PAL/NTSCMin. Illumination|Color0.01 Lux @(F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON), 0 Lux with IRShutter time|1/3 s to 1/100,000 sSlow shutter|SupportLens|Horizontal FOV: 99.6° to 35°, vertical FOV: 53.5° to 20°, diagonal FOV: 118.6° to 40.2°Lens Mount|φ14Adjustment Range|Pan: 0° to 360°, tilt: 0° to 100°, rotation: 0° to 360°Day& Night|IR cut filter with auto switchWide Dynamic Range|120 dBDigital noise reduction|3D DNRFocus|AutoVideo Compression|H.265+/H.265/H.264+/H.264/MJPEGVideo bit rate|32Kbps~8MbpsAudio Compression|G.711/G.722.1/G.726/MP2L2/PCMAudio bit rate|64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)Max. Image Resolution|1920 x 1080Frame Rate|50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)Sub Stream|50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)Image Enhancement|BLC/3D DNRImage Settings|Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browserTarget Cropping|NoBLC|SupportROI|1 fixed region for main stream and sub-streamDay/Night Switch|Day/Night/Auto/Schedule/Triggered by alarm in (-S)Network Storage|microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANRAlarm Trigger|Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD errorProtocols|TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, BonjourGeneral Function|One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filteringSystem Compatibility|ONVIF (Profile S, Profile G),ISAPIAudio|1 audio input (line in), 1 audio output (line out), mono soundCommunication Interface|1 RJ45 10M / 100M Ethernet interfaceAlarm|2 inputs, 2 outputsVideo Output|1Vp-p Composite Output(75Ω/CVBS) (For adjustment only)On-board storage|Built-in Micro SD/SDHC/SDXC slot, up to 128 GBReset Button|YesEnvironment Noise Filtering|SupportAudio Sampling Rate|8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHzBehavior Analysis|Line crossing detection, intrusion detectionLine Crossing Detection|Cross a pre-defined virtual lineIntrusion Detection|Enter and loiter in a pre-defined virtual regionOperating Conditions|-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)Power Supply|12 VDC ± 25%, PoE (802.3af Class3)Power Consumption|–Z: 12 VDC, 0.9 A, max. 11 W PoE: (802.3af, 36V-57V), 0.4 A to 0.2 A, max. 12.9 W Without –Z: 12 VDC, 0.6 A, max. 7W PoE: (802.3af, 36V-57V), 0.3 A to 0.1 A, max. 9 WWeather Proof|IP67IR Range|Up to 30mDimensions|Φ 105 × 294.5 mm (Φ 4.1" × 11.6")Weight|Camera: approx. 1050 g (2.3 lb.) With package: approx. 1500 g (3.3 lb.)
